Copper-accelerated Acetic-Acid Salt Spray (CASS) testing is an essential quality control corrosion test used to evaluate the durability of corrosion-resistant materials like anodized aluminium and plated metals. By combining a highly corrosive, acidic salt solution with a high-temperature fog, CASS testing accelerates the corrosion process, allowing manufacturers to assess the longevity and performance of their materials under extreme conditions. The most widely recognized standards for CASS testing are ISO 9227 CASS and ASTM B368, although many international tests adhere to similar protocols.
Challenges in CASS Testing
One of the primary challenges in conducting CASS testing is balancing the collection requirements and the mass loss requirements simultaneously. In many traditional corrosion chambers, maintaining high-temperature conditions can lead to significant evaporation of the solution. This evaporation results in low-volume, high-concentration collections, which can skew the test results. Attempting to increase the volume of the solution to compensate for this can lead to over-corrosion of the mass loss coupons, thereby failing to meet the test’s stringent standards.
The Solution: Q-FOG CCT Cyclic Corrosion Tester
The Q-FOG CCT Cyclic Corrosion Tester offers a unique solution to these challenges. Unlike traditional corrosion chambers, the Q-FOG CCT tester is equipped with a vapour generator that works in conjunction with the chamber's heating system. This dual functionality allows the chamber to maintain high humidity levels, effectively reducing the evaporation rate of the solution. As a result, the Q-FOG CCT tester can produce consistent collections while also meeting the mass loss requirements, ensuring full compliance with CASS testing standards.
Advanced Features for Optimal Performance
Q-Lab emphasizes the use of extreme environment heaters within the Q-FOG CCT chambers to perform CASS testing. These heaters are constructed from a highly corrosion-resistant metal alloy, designed specifically to withstand the aggressive nature of the CASS solution. This advanced material choice extends the life of the heaters and ensures consistent performance throughout the testing process.
Benefits of Using Q-FOG CCT Testers
-
Simultaneous Compliance: The ability to control both temperature and humidity allows Q-FOG CCT testers to meet the rigorous collection and mass loss requirements of CASS testing concurrently.
-
Enhanced Durability: The use of corrosion-resistant metal alloys in the chamber heaters ensures longevity and reliability, even under extreme testing conditions.
-
Accurate Results: By maintaining consistent environmental conditions, the Q-FOG CCT tester provides accurate and reliable corrosion test results, helping manufacturers ensure the quality and durability of their materials.
-
Versatility: While designed to meet CASS testing requirements, the Q-FOG CCT tester is also versatile enough to perform a wide range of other cyclic corrosion tests, making it a valuable tool in various quality control applications.
Conclusion
Meeting the stringent requirements of CASS testing can be challenging, but the Q-FOG CCT Cyclic Corrosion Tester from Q-Lab offers a robust solution. By effectively managing the balance between humidity and temperature and incorporating advanced corrosion-resistant materials, the Q-FOG CCT tester ensures accurate and reliable test results. This makes it an indispensable tool for manufacturers looking to guarantee the quality and durability of their corrosion-resistant materials.
