Shaker Refrigerated Incubator TMLR-200

This Australian-made refrigerated incubator is designed to maintain a temperature-controlled environment for laboratory equipment with heat output up to 200 watts, such as a shaker.

Get a quote

Overview

The temperature is factory set at 22°C and the cabinet can operate up to a 30°C ambient. Forced air circulation ensures uniform airflow and temperature control. The incubator features a key lockable glass door, password-protected controller, and castors for easy movement.

Key Features

STAR X 10" Touchscreen Control System: Easily adjust and program temperature and humidity settings, synchronise settings to real-time, and perform all functions via a PC with ethernet connectivity.
Advanced Data Logging: Logs up to 365 days of performance data, viewable in real-time, and downloadable onto a USB flash drive or an Excel spreadsheet.
Safety and Convenience: Includes a battery backup for continued logging and alarms during power loss, and an auto-test feature for quick alarm or calibration tests.

Benefits

Consistent Temperature Control: Ensures stable conditions for sensitive samples with precise temperature regulation and uniform airflow.
Comprehensive Monitoring: The STAR X system provides detailed performance tracking and easy access to historical data, enhancing laboratory efficiency.
Enhanced Security and Mobility: Features like the key lockable door, password-protected controller, and castors ensure secure and convenient operation.

Note: This product is not a registered medical device.

Specifications

Dimensions

	TMLR-200
External
WxDxH (mm)	740x840x1100
Internal
WxDxH (mm)	600x550x530
Clearance
Front (mm)	740
Back (mm)	100
Sides (mm)	100

Technical Specifications

	TMLR-200
Temperature Range	Factory set at 22°C with alarm setpoints at 20.5°C and 23.5°C
Temperature Control Stability	+/- 0.1°C
Temperature Uniformity	+/- 1.0°C
Nominal Capacity	200L
Refrigeration	Internal equipment maximum heat output of 200 watts
Porthole Diameter	1x 13mm, 1x 54mm
Weight	90kg
Electrical	450W/230V

Features

	TMLR-200
Castors	✔
Fan Forced Air Circulation	✔
STAR 700 7" Touch Screen Controller	✔
Door Lock	✔
BMS Plug	✔
Ecofoam Insulation	✔

Safety

	TMLR-200
Over Current Protection	✔
Over Temperature Safety	✔

Options

	TMLR-200
Adjustable Feet	On request
