Vortex Mixer TVM-1

Small footprint with maximum mixing power.

The Vortexer offers immediate vortex shaking for a variety of tube sizes. Its simple touch-start operation enables exceptional mixing performance with one hand.

Get a quote Buy Online

Overview

The Thermoline Mini Vortexer is an essential laboratory tool designed for efficient and versatile sample mixing. Whether you need gentle shaking or rapid mixing, this vortexer offers precise control and robust performance for a variety of applications.

Key Features:

  • Variable Speed: Adjustable from 0 to 3000 rpm, allowing for gentle shaking to rapid mixing of samples.
  • Touch Operation Mode: Simple and intuitive operation for ease of use.
  • Excellent Mixing Capability: Provides thorough and consistent mixing results.
  • Perfect Dynamic Balance Design: Eliminates any movement during mixing, ensuring stability.
  • Interchangeable Attachments: Suitable for various applications with different attachments.
  • Durable Construction: Brushless DC motor and sturdy iron/aluminium casting base for long-lasting use.
  • Low Operation Voltage: Operates at 12V for full protection and safety.
  • Orbital Diameter: 6mm for effective mixing.

Specifications:

  • Speed: Adjustable 0 to Max 3000 rpm
  • Orbit: 6 mm
  • Capacity: Up to 50 mL tube
  • Weight: 1 kg

Package Includes:

  • 1x Mini Vortexer
  • 1x Silicone Cap
  • 1x Low voltage, double insulated power adaptor

Optional Attachments (requires TVM-14 Universal top plate):

  • Test Tube Attachments:
    • 54 x Ø6mm
    • 18 x Ø10mm
    • 12 x Ø12mm
    • 8 x Ø16mm
    • 8 x Ø20mm
  • Erlenmeyer Flask Attachment: 100-250ml
  • Microtiter Plate Attachment
  • Platform Pad for Ø99mm Tubes and Small Vessels



The Thermoline Mini Vortexer is a reliable and versatile solution for all your laboratory mixing needs. With its robust design and range of attachments, it ensures precise and efficient mixing for a variety of sample types.

Specifications

Dimensions
  TVM-1
External
WxDxH (mm) 107x166x146



Technical Specifications
  TVM-1
Operation Mode Continuous/Touch Operation
Type of Movement Orbital
Speed Range (rpm) 0-3000
Orbital Diameter 6mm
Electrical 36W/230V
Weight 2.6kg



Downloads

Support & FAQs

At Thermoline, we strive to supply helpful customer support to ensure that you get the most out of our products. We are committed to providing whatever support our customers need, wherever they are in the world. If you can't find your solution in the below FAQs or Knowledge Base, please contact our friendly support team.

What does a vortex mixer do?
A vortex mixer, an essential tool in laboratories, swiftly blends samples with its high-speed rotation despite its compact size. Widely applicable across various fields such as microbiology, biochemistry, bioscience, and analytical labs, it efficiently facilitates mixing processes.
What is the difference between a vortex mixer and a shaker?
An orbital shaker is designed to mix larger liquid volumes for extended durations, contrasting with the rapid mixing of smaller liquid volumes achieved by a vortex mixer.
What is the difference between a vortex mixer and a centrifuge?
Centrifuges separate particles within a liquid mixture according to density, whereas vortex mixers swiftly and effectively blend liquid samples.
